Conforms to 9.3mm maximum diameter rule
-
Lightweight shaft
-
Range of spine sizes to fit the setups of most target archers
-
Highly adjustable point weight system with screw in point weights for a better tune
Technical specifications:
Material:
|
All carbon
|
Diameter:
|
9.3mm max
|
Straightness Tolerance:
|
±0.0025"
|
Weight Tolerance:
|
±1 grain
|
Available Spines:
|
150, 250, 350
|
Uncut length (approx):
|
32.5"
|
Included components:
|
Bulldog nock collar included
|
Designed for:
|
FITA/WA, IFAA and NAA
|
Specifications and Components: Components listed are those produced by CX only. Other components may fit!
SIZE
|
Weight (GPI)
|
SPINE
|
Diameter (inch)
|
Parabolic Point
|
Pin Point
|
Pin Nock Adaptor*
|
Nock*
|
Nock bushing
|
Insert
|
150
|
6.0
|
0.502
|
0.318
|
108351-1000
|
not available
|
108378-1000
|
108370-1000
|
not available
|
not available
|
250
|
6.47
|
0.414
|
0.350
|
108359-1024 108359-1036
|
108356-1000
|
108376-1000
|
108370-1000 108398-1000
|
108375-1012
|
108355-1000
|
350
|
7.14
|
0.354
|
0.353
|
108359-1024 108359-1036
|
108356-1000
|
108376-1000
|
108370-1000 108398-1000
|
108375-1012
|
108355-1000
|
obs: Udgår!
